Double-Winged Shipping Container offers a unique and innovative living solution for people who want to live simply, comfortably, and sustainably. With a variety of layouts to choose from, you can create the perfect living space for your unique needs!
| SIN-20DZ expandable Container | |||
| Folded size 5800(L)*2200(W)*2530mm(H) Expanded size 5800(L)*6400(W)*2530mm(H) | 50 wall | ||
| Three glass doors are double-glazed, one glass wall is double-layered, the bathroom partition uses a glass sliding door to require a roof, the outer wall is 50 thick, the outer wall is metal hanging panels, cabinets, water pipes, electrical appliances, Australian standards, a total of 3 outer doors plus 2 inner doors plus 1 glass sliding door 5 windows of 930 plus 1 window of 600. | |||
| Galvanized steel frame 120mm*60mm*2.5/80mm*80mm1.5/20mm*40mm*1.0 (ceiling bracket) 10*20*1.0 (water purlin) | 1 | ||
| Galvanized steel frame 120mm*60mm*2.5/80mm*80mm2.0/80mm*40mm2.0 | 1 | ||
| Galvanized steel frame 80mm*80mm2.0/80mm*40mm2.0//1.5mm U-shaped closure/L-shaped, Z-shaped water baffle | 1 | ||
| Galvanized steel pipe 150*150*3mm/80*80*2.5 | 4 | ||
| 210*160*140mm national standard special marine cast iron hanger / top 4 sets, bottom 4 sets | 8 | ||
| 50mm thick EPS sandwich cleaning board, double-sided 0.4mm thick color steel plate; partition board 50mm | 1 | ||
| Side 50mm thick EPS sandwich panel, double-sided 0.4mm thick color steel plate | ㎡ | 29 | |
| 06mm container top corrugated steel plate | ㎡ | 29 | |
| 15mm thick cement floor plus plywood plus PVC floor leather decorative layer | m³ | 90 | |
| Heavy Duty Steel Hinge 15mm, 10mm | 1 | ||
| Aluminum alloy thermal insulation bridge tempered glass 1930*2000mm | 3 | ||
| Aluminum alloy sliding window 1100*930/swivel ears, double-layer tempered glass wall 1 side | 5 | ||
| 15mm modified floor, 15mm plastic wood floor | ㎡ | 38 | |
| 1 | |||
| 16mm metal insulation carved panels, decorative hanging panels for exterior walls | 1 | ||
| 1 | |||
| 1 | |||
| 1 | |||
| 4 | |||
| 120 | |||
| 4 | |||
| 380 | |||
| 1 | |||
| 793 structural adhesive, 995 silicone weather-resistant adhesive, transparent glass adhesive | 1 | ||
| L-shaped countertop, artificial marble countertop, including basin, hardware and stainless steel parts, near the drainage pipe | 1 | ||
| 800 fan-shaped tempered glass shower with shower head, straight toilet, floor drain, cosmetic mirror, ceramic washbasin, wall cabinet, exhaust fan, | 1 | ||
| PPR25 water inlet pipe (cold water, hot water pipe), quick connector, sewage pipe (PVC110 stool), pvc50 pipe, vegetable washing sewage pipe, wrapped with thermal insulation and antifreeze cotton | 1 | ||
